COURTESY LIGHTS - Wiring diagram

Make

Fiat

Model

Panda Factory Service Manual

Year

2003–2012

Section

Interior lighting › COURTESY LIGHTS - Wiring diagram

Wiring diagrams and electrical functionsCOURTESY LIGHTS - Wiring diagram

COURTESY LIGHTS - Wiring diagram

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit	5505C
B1	engine compartment junction unit	5505C
C20	Passenger side dashboard earth
C30	Left rear earth
D30	Front left door connection
D31	Front right door connection
D35	Rear left door connection
D36	Rear right door connection
E50	Instrument panel	5560B
G10	Front courtesy light	7040E
G40	Boot courtesy light
H1	Ignition switch	5520A
I16	Switch on left front door
I16	Switch on left front door.
I33	Switch on boot outer handle	7015B
I50	Inertia switch	1040A
I50	Inertial switch	1040A
M1	Body computer	5505A
N50	Left front door lock geared motor	7005N
N51	Right front door lock geared motor	7005N
N55	Left rear door lock geared motor	7010N
N56	Right rear door lock geared motor	7010N

Door lock

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit	5505C
B1	engine compartment junction unit	5505C
C20	Passenger side dashboard earth
C30	Left rear earth
D30	Front left door connection
D31	Front right door connection
D35	Rear left door connection
D36	Rear right door connection
E50	Instrument panel	5560B
G10	Front courtesy light	7040E
G40	Boot courtesy light
H1	Ignition switch	5520A
I16	Switch on left front door
I16	Switch on left front door.
I33	Switch on boot outer handle	7015B
I50	Inertia switch	1040A
I50	Inertial switch	1040A
M1	Body computer	5505A
N50	Left front door lock geared motor	7005N
N51	Right front door lock geared motor	7005N
N55	Left rear door lock geared motor	7010N
N56	Right rear door lock geared motor	7010N
