INSTRUMENT LIGHTING - Wiring diagram
- Make
- Fiat
- Model
- Panda Factory Service Manual
- Year
- 2003–2012
- Section
- Interior lighting › INSTRUMENT LIGHTING - Wiring diagram
Wiring diagrams and electrical functionsINSTRUMENT LIGHTING - Wiring diagram
INSTRUMENT LIGHTING - Wiring diagram
Wiring diagram
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | Engine compartment junction unit | 5505C |
| B1 | engine compartment junction unit | 5505C |
| B2 | Junction unit under dashboard | 5505C |
| C16 | Air conditioning earth | |
| C20 | Passenger side dashboard earth | |
| D1 | Front dashboard coupling | |
| D1 | Front / dashboard coupling | |
| D1 | front / dashboard coupling | |
| D21 | Dashboard air conditioner heater connection | |
| D21 | Dashboard / air conditioner - heater connection | |
| D75 | Radio phone junction | |
| D75 | Radio phone connection | |
| D97 | Short circuiting coupling | |
| E50 | Instrument panel | 5560B |
| G45 | Air conditioning heater controls light | |
| G45 | Air conditioning / heater controls light | |
| H1 | Ignition switch | 5520A |
| H5 | Steering column switch unit | 5550A |
| M1 | Body computer | 5505A |
| M70 | Climate control system control unit | 5040D |
| M94 | Radio Receiver Node | |
| P50 | Cigar lighter current socket | 7065C |
| P50 | Cigar lighter / current socket | 7065C |
