Wiring diagrams and electrical functions RADIO - Location of components
RADIO - Location of components
Hi-Fi
Location of components
COMPONENTS
Component code Name Assembly reference B1 Engine compartment junction unit 5505A B2 Junction unit under dashboard 5505A B45 Luggage compartment junction unit B99 Maxifuse box on battery 5530B C15 Facia earth, driver's side C30 Left rear earth D30 Rear coupling for /front door. driver's side D31 /Front passenger door. rear coupling D31 Front passenger door/ rear coupling. D35 Left /rear door. coupling D35 Rear / rear door coupling left D36 Rear/right door coupling right D36 Right /rear door. rear coupling D41 Rear dashboard/ coupling for speakers D47 Clock spring coupling 5580C D68 HI system junction D97 Short circuiting coupling H1 Ignition switch 5520A M1 Body computer 5505A P20 Car radio 5570T P20 Radio 5570T P25 Aerial P30 Left rear speaker 5580T P31 Right rear speaker 5580T P35 Speaker in driver's .front door 5580T P36 Speaker in front passenger door 5580T P45 Driver's front tweeter speaker 5570T P46 Front passenger side tweeter speaker 5570T P47 Rear left tweeter speaker P47 Rear left tweeter speaker 5570T P48 Rear right tweeter speaker P49 Rear subwoofer speaker 5570T P70 HIFI radio amplifier
Location of components
COMPONENTS
Component code Name Assembly reference B1 Engine compartment junction unit 5505A B2 Junction unit under dashboard 5505A B45 Luggage compartment junction unit B99 Maxifuse box on battery 5530B C15 Facia earth, driver's side C30 Left rear earth D30 Rear coupling for /front door. driver's side D31 /Front passenger door. rear coupling D31 Front passenger door/ rear coupling. D35 Left /rear door. coupling D35 Rear / rear door coupling left D36 Rear/right door coupling right D36 Right /rear door. rear coupling D41 Rear dashboard/ coupling for speakers D47 Clock spring coupling 5580C D68 HI system junction D97 Short circuiting coupling H1 Ignition switch 5520A M1 Body computer 5505A P20 Car radio 5570T P20 Radio 5570T P25 Aerial P30 Left rear speaker 5580T P31 Right rear speaker 5580T P35 Speaker in driver's .front door 5580T P36 Speaker in front passenger door 5580T P45 Driver's front tweeter speaker 5570T P46 Front passenger side tweeter speaker 5570T P47 Rear left tweeter speaker P47 Rear left tweeter speaker 5570T P48 Rear right tweeter speaker P49 Rear subwoofer speaker 5570T P70 HIFI radio amplifier
Right hand drive
Location of components
COMPONENTS
Component code Name Assembly reference B1 Engine compartment junction unit 5505A B2 Junction unit under dashboard 5505A B45 Luggage compartment junction unit B99 Maxifuse box on battery 5530B C15 Facia earth, driver's side C30 Left rear earth D30 Rear coupling for /front door. driver's side D31 /Front passenger door. rear coupling D31 Front passenger door/ rear coupling. D35 Left /rear door. coupling D35 Rear / rear door coupling left D36 Rear/right door coupling right D36 Right /rear door. rear coupling D41 Rear dashboard/ coupling for speakers D47 Clock spring coupling 5580C D68 HI system junction D97 Short circuiting coupling H1 Ignition switch 5520A M1 Body computer 5505A P20 Car radio 5570T P20 Radio 5570T P25 Aerial P30 Left rear speaker 5580T P31 Right rear speaker 5580T P35 Speaker in driver's .front door 5580T P36 Speaker in front passenger door 5580T P45 Driver's front tweeter speaker 5570T P46 Front passenger side tweeter speaker 5570T P47 Rear left tweeter speaker P47 Rear left tweeter speaker 5570T P48 Rear right tweeter speaker P49 Rear subwoofer speaker 5570T P70 HIFI radio amplifier
19 Electrical
