Wiring diagrams and electrical functions Abs wiring diagram
ABS WIRING DIAGRAM
2.4 20V, 3.0 V6, 3.2 V6 · Automatic Transmission
Wiring Diagram
Components
Component code Name Assembly reference B001 Engine compartment junction unit 5505A B002 Junction unit under dashboard C010 Left front earth C012 C022 Centre dashboard earth D001 D097 Short circuit coupling E050 Instrument panel H001 Ignition switch I030 Interruttore pedale freno 5520G I031 Clutch pedal switch K070 3340A K071 Right front wheel sensor for ABS K075 Left rear wheel sensor for ABS K076 3340A M001 Body computer M010 Engine management control unit 1056B M051 Braking system control unit (NFR) M089 Steering lock control unit (NBS)
2.4 JTD 10V, 2.4 JTD 20V
Wiring Diagram
Components
Component code Name Assembly reference B001 Engine compartment junction unit 5505A B002 Junction unit under dashboard C012 C022 Centre dashboard earth D001 D097 Short circuit coupling E050 Instrument panel H001 Ignition switch I030 Interruttore pedale freno 5520G K070 3340A K071 Right front wheel sensor for ABS K075 Left rear wheel sensor for ABS K076 3340A M001 Body computer M010 Engine management control unit 1056B M051 Braking system control unit (NFR)
2.0 TB, 2.4 20V
Wiring Diagram
Components
Component code Name Assembly reference B001 Engine compartment junction unit 5505A B002 Junction unit under dashboard C012 C022 Centre dashboard earth D097 Short circuit coupling E050 Instrument panel H001 Ignition switch I030 Interruttore pedale freno 5520G K070 3340A K071 Right front wheel sensor for ABS K075 Left rear wheel sensor for ABS K076 3340A M001 Body computer M010 Engine management control unit 1056B M051 Braking system control unit (NFR)
19 Electrical
