Alarm wiring diagram
- Make
- Lancia
- Model
- Thesis Factory Service Manual
- Year
- 2002–2009
- Section
- Vehicle electronic systems › Alarm wiring diagram
Wiring diagrams and electrical functionsAlarm wiring diagram
ALARM WIRING DIAGRAM
Wiring Diagram
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C010 | Left front earth | |
| C011 | Right front earth | |
| C015 | Driver''s dashboard earth | |
| C022 | Centre dashboard earth | |
| C030 | Left rear earth | |
| C031 | Right rear earth | |
| D097 | Short circuit coupling | |
| E050 | Instrument panel | |
| H001 | Ignition switch | |
| D040 | Rear/boot coupling | |
| F055 | No. plate lights and external boot opening switch | |
| I010 | Bonnet release switch | |
| M001 | Body computer | |
| M062 | 7040E | |
| M063 | Luggage compartment control unit (NVB) | |
| P090 | 5580E | |
| P093 | Aerial for alarm and central locking receiver |
Wiring Diagram
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C010 | Left front earth | |
| C011 | Right front earth | |
| C015 | Driver''s dashboard earth | |
| C020 | ||
| C030 | Left rear earth | |
| C031 | Right rear earth | |
| D030 | Left front door coupling | |
| D031 | ||
| D035 | Left rear door coupling | |
| D036 | ||
| D040 | Rear/boot coupling | |
| D097 | Short circuit coupling | |
| E050 | Instrument panel | |
| H001 | Ignition switch | |
| I010 | Bonnet release switch | |
| I022 | 7005C | |
| I023 | Switch on passenger side exterior handle | 7005C |
| M001 | Body computer | |
| M062 | 7040E | |
| M063 | Luggage compartment control unit (NVB) | |
| M064 | Passive entry control unit (NPE) | 5580E |
| M066 | Driver''s door control unit (NPG) | 7005M |
| M067 | Passenger door control unit (NPP) | 7005M |
| P013 | Boot aerial | |
| P015 | Passive entry control unit RF aerial (NPE) | |
| P076 | 5580E | |
| P077 | RF aerial on tunnel for passive entry (NPE) | 5580E |
| P078 | RF aerial in dashboard for passive entry (NPE) | |
| P090 | 5580E | |
| P094 | RF aerial on left front door for passive entry (NPE) | 5580E |
| P095 | RF aerial on right front door for passive entry (NPE) | 5580E |
| P096 | RF aerial on left rear door for passive entry (NPE) | 5580E |
| P097 | RF aerial on right rear door for passive entry (NPE) | 5580E |
| P098 | RF aerial on rear bumper for passive entry (NPE) | |
| P099 | RF aerial for Fiat code passive entry (NPE) |
