Esp wiring diagram
- Make
- Lancia
- Model
- Thesis Factory Service Manual
- Year
- 2002–2009
- Section
- Vehicle electronic systems › Esp wiring diagram
Wiring diagrams and electrical functionsEsp wiring diagram
ESP WIRING DIAGRAM
Wiring Diagram
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B001 | Engine compartment junction unit | 5505A |
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C011 | Right front earth | |
| C012 | ||
| C022 | Centre dashboard earth | |
| D097 | Short circuit coupling | |
| E050 | Instrument panel | |
| H001 | Ignition switch | |
| I030 | Interruttore pedale freno | 5520G |
| K070 | 3340A | |
| K071 | Right front wheel sensor for ABS | |
| K075 | Left rear wheel sensor for ABS | |
| K076 | 3340A | |
| M001 | Body computer | |
| M010 | Engine management control unit | 1056B |
| M051 | Braking system control unit (NFR) | |
| M091 | Slewing control unit | |
| M092 | Steering angle control unit (NAS) |
Wiring Diagram
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B001 | Engine compartment junction unit | 5505A |
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C010 | Left front earth | |
| C011 | Right front earth | |
| C012 | ||
| C022 | Centre dashboard earth | |
| D006 | Front/rear coupling | |
| D097 | Short circuit coupling | |
| E050 | Instrument panel | |
| H001 | Ignition switch | |
| I030 | Interruttore pedale freno | 5520G |
| K070 | 3340A | |
| K071 | Right front wheel sensor for ABS | |
| K075 | Left rear wheel sensor for ABS | |
| K076 | 3340A | |
| M001 | Body computer | |
| M010 | Engine management control unit | 1056B |
| M051 | Braking system control unit (NFR) | |
| M091 | Slewing control unit | |
| M092 | Steering angle control unit (NAS) |
Wiring Diagram
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B001 | Engine compartment junction unit | 5505A |
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C011 | Right front earth | |
| C012 | ||
| C022 | Centre dashboard earth | |
| D006 | Front/rear coupling | |
| D097 | Short circuit coupling | |
| E050 | Instrument panel | |
| H001 | Ignition switch | |
| I030 | Interruttore pedale freno | 5520G |
| K070 | 3340A | |
| K071 | Right front wheel sensor for ABS | |
| K075 | Left rear wheel sensor for ABS | |
| K076 | 3340A | |
| M001 | Body computer | |
| M010 | Engine management control unit | 1056B |
| M051 | Braking system control unit (NFR) | |
| M091 | Slewing control unit | |
| M092 | Steering angle control unit (NAS) |
