AUTOMATIC TRANSMISSION LOCATION COMPONENTS
Location Components
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B001 | Engine compartment junction unit | 5505A |
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C010 | Left front earth | |
| C011 | Right front earth | |
| C012 | ABS front earth | |
| C022 | Centre dashboard earth | |
| D006 | Front/rear coupling | |
| D097 | Short circuit coupling | |
| E050 | Instrument panel | |
| I030 | Interruttore pedale freno | 5520G |
| L050 | Automatic transmission solenoid valves | 2130B |
| L057 | ||
| M001 | Body computer | |
| M053 | 2130B | |
| M051 | Braking system control unit (NFR) | |
| M055 | Automatic transmission control unit |
