CONTROLLED SUSPENSION LOCATION COMPONENTS
Location Components
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B001 | Engine compartment junction unit | 5505A |
| B002 | Junction unit under dashboard | 5505A |
| C011 | Right front earth | |
| C012 | ||
| C022 | Centre dashboard earth | |
| D001 | ||
| D097 | Short circuit coupling | |
| E050 | Instrument panel | |
| H001 | Ignition switch | |
| I030 | Interruttore pedale freno | 5520G |
| K006 | Left front vertical acceleration sensor | |
| K007 | Right front vertical acceleration sensor | |
| K008 | Vertical acceleration sensor on left front wheel | |
| K009 | Vertical acceleration sensor on left front wheel | |
| K011 | ||
| K012 | ||
| M001 | Body computer | |
| M046 | ||
| M051 | Braking system control unit (NFR) | |
| N096 | ||
| N097 | ||
| N098 | ||
| N099 | SCS left rear actuator |
