SERVOTRONIK DEVICE WIRING DIAGRAM
Wiring Diagram
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B001 | Engine compartment junction unit | 5505A |
| B002 | Junction unit under dashboard | |
| C011 | Right front earth | |
| C012 | ||
| C022 | Centre dashboard earth | |
| D001 | ||
| D097 | Short circuit coupling | |
| E050 | Instrument panel | |
| H001 | Ignition switch | |
| L070 | ||
| M001 | Body computer | 5505A |
| M051 | Braking system control unit (NFR) | |
| M088 | Servotronik control unit | 4130C |
