Electric handbrake location components
- Make
- Lancia
- Model
- Thesis Factory Service Manual
- Year
- 2002–2009
- Section
- Vehicle electronic systems › Electric handbrake location components
Wiring diagrams and electrical functionsElectric handbrake location components
ELECTRIC HANDBRAKE LOCATION COMPONENTS
Location Components
Components
| Component code | Name | Assembly reference |
|---|---|---|
| A055 | Additional battery for parking control unit (NPB) | |
| B001 | Engine compartment junction unit | 5505A |
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C010 | Left front earth | |
| C012 | ||
| C015 | Driver''s dashboard earth | |
| C022 | Centre dashboard earth | |
| C031 | Right rear earth | |
| C057 | ||
| D001 | ||
| D020 | ||
| D033 | Left rear/brake caliper coupling | |
| D034 | ||
| D037 | Giunzione posteriore / mobiletto centrale | |
| E050 | Instrument panel | |
| H001 | Ignition switch | |
| H008 | ||
| I030 | Interruttore pedale freno | 5520G |
| I035 | Safety switch on brake pedal for cruise control | |
| I041 | Electric brake emergency release switch | |
| K055 | 1068A | |
| L050 | Automatic transmission solenoid valves | 2130B |
| M001 | Body computer | |
| M010 | Engine management control unit | 1056B |
| M059 | Electric brake control unit | |
| M065 | Info-telematic control unit (NIT) | 5580P |
| N088 | Left rear brake caliper motor | |
| N089 | Right rear brake caliper motor |
