Wiring diagrams and electrical functionsAirbag wiring diagram
AIRBAG WIRING DIAGRAM
Wiring Diagram
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B002 | Junction unit under dashboard | |
| C022 | Centre dashboard earth | |
| C050 | Air Bag system earth | |
| C055 | Side Bag system earth | |
| D020 | ||
| D038 | Rear dashboard coupling for pretensioners/side bag (left), | |
| D039 | Pretensioner/Side Bag (left) rear dashboard coupling | |
| D047 | ||
| D070 | Driver''s seat coupling | |
| D071 | Passenger seat coupling | |
| E050 | Instrument panel | |
| H001 | Ignition switch | |
| H075 | Passenger Air Bag disabling switch | 5580C |
| H076 | ||
| I046 | DRIVER''S SEAT BELT SWITCH | |
| I047 | ||
| K037 | ||
| K038 | ||
| K066 | 5580C | |
| K067 | Sensor for passenger Air Bag | 5580C |
| M001 | Body computer | |
| M060 | Air Bag control unit | |
| Q009 | DRIVER''S AIR BAG | |
| Q011 | 5580C | |
| Q020 | 7065A | |
| Q021 | 7065A | |
| Q022 | 7065B | |
| Q023 | Passenger side rear seat belt pretensioner | 7065B |
| Q030 | Driver''s sidebag | 5580C |
| Q031 | 5580C | |
| Q040 | Driver''s Head Bag | 5580C |
| Q041 | Passenger Head Bag | 5580C |
| Q042 | 5580C | |
| Q043 | Right rear Air Bag | 5580C |
