Discovery II
FRONT SUSPENSION
REPAIRS
60-39
ECU - ACE
$% 60.60.01
Remove
1. Remove BCU.
2. Remove 5 multiplugs from SLABS ECU.
3. Remove multiplug from ACE ECU.
4. Remove lower nut and loosen upper nut
securing SLABS and ACE ECU bracket to
body.
5. Remove ECU's and bracket assembly.
6. Remove 3 nuts securing ACE ECU and remove
ACE ECU.
Refit
1. Fit ACE ECU to bracket and secure with nuts.
2. Fit ECU's and bracket assembly to body and
secure with nuts.
3. Connect multiplugs to ACE ECU and SLABS
ECU.
4. Fit BCU.
5. If a replacement ACE ECU has been fitted, use
TestBook to calibrate ACE system.
