Discovery II
RESTRAINT SYSTEMS
75-16
REPAIRS
Mounting - seat belt - 'B' post
$% 76.73.26
Remove
1. Release front door aperture seal from 'B' post.
2. Release rear door aperture seal from 'B' post.
3. Release clip securing upper 'B' post trim.
4. Remove 'B' post upper trim.
5. Remove nut securing seat belt upper
anchorage to mounting.
6. Remove 2 Torx bolts securing mounting to 'B'
post.
7. Remove mounting.
Refit
1. Fit mounting to 'B' post and tighten Torx bolts to
22 Nm (16 lbf.ft).
2. Fit seat belt upper anchorage to mounting and
tighten nut to 32 Nm (24 lbf.ft).
3. Secure trim casing to 'B' post with clip.
4. Fit front and rear door aperture seals to 'B'
post.
