Discovery II
RESTRAINT SYSTEMS
REPAIRS
75-17
Seat belts - third row
$% 76.73.28/21
Remove
1. Remove 'D' post trim casing.
REPAIRS, Trim casing - 'D' post.
2. Remove seat belt upper anchorage bolt and
collect spacer.
3. Release access panel from loadspace side trim
casing.
4. Remove access panel.
5. Remove bolt securing seat belt reel to body.
6. Remove cap from seat belt lower anchorage
bolt.
7. Remove lower anchorage bolt and collect
washers.
8. Remove seat belt.
Refit
1. Fit seat belt lower anchorage to body and
tighten bolt to 32 Nm (24 lbf.ft). Fit cap to bolt.
2. Fit seat belt reel to body and tighten bolt to 50
Nm (37 lbf.ft).
3. Fit seat belt upper anchorage and tighten bolt
to 50 Nm (37 lbf.ft).
4. Fit access panel to luggage compartment side
trim casing.
5. Fit 'D' post trim casing.
