Discovery II
RESTRAINT SYSTEMS
75-18
REPAIRS
Pre-tensioner - front seat belt
$% 76.73.30
WARNING: It is imperative that before any work
is undertaken on the SRS system the appropriate
information is read thoroughly.
WARNING: Always disconnect both battery leads
before beginning work on the SRS system.
Disconnect the negative battery lead first. Never
reverse connect the battery.
Remove
1. Remove the key from the starter switch.
Disconnect both battery leads, negative lead
first. Wait ten minutes before starting work.
2. Remove front seat.
3. Release cable tie securing pre-tensioner
harness to seat.
4. Remove Torx screw securing pre-tensioner to
seat.
5. Remove pre-tensioner.
WARNING: Store the airbag module or seat
belt pre-tensioner in a designated storage
area. If there is no designated storage area
available, store in the locked luggage
compartment/loadspace of the vehicle and
inform the workshop supervisor.
Refit
1. Fit pre-tensioner to seat and tighten Torx bolt to
32 Nm (24 lbf.ft).
2. Secure harness to seat with new cable tie.
3. Fit front seat.
4. Connect battery leads, earth lead last.
