’B/c’ post reinforcement - 5 door (page 2 of 2)

Make

Land Rover

Model

Freelander Body Repair Manual

Year

1998 on

Section

Repairs

Panel repairs’B/c’ post reinforcement - 5 door · page 2 of 2

Refit

1. Secure vehicle harness to inner sill.
2. Position carpet to inner sill.
3. Fit side door aperture seal(s).
4. Fit treadplate from side door aperture(s).
5. Fit rear seat. See BODY, Seats and seat belts.
6. Fit front seat. See BODY, Seats and seat belts.
7. Fit front door striker to B/C post.
8. Fit B/C post lower finisher. See BODY, Interior trim components.
9. Fit front seat belt. See RESTRAINT SYSTEMS, Repairs.
10. Fit headlining. See BODY, Interior trim components.
11. Fit rear door. See BODY, Doors.
12. Connect all ECUs.
13. Connect alternator. See ELECTRICAL, Repairs.
14. Connect battery earth lead.
