For driver’s side

Refit

For driver’s side

1. Fit passenger compartment fuse box.

For both sides

2. Fit insulation pads to engine bulkhead.
3. Fit front door aperture seal.
4. Position front carpet and fit treadplate to front door aperture.
5. Fit headlining. See BODY, Interior trim components.
6. Fit windscreen. See BODY, Screens.
7. Fit duct of outboard face level ventilator.
8. Fit fascia. See BODY, Interior trim components.
9. Fit front seat. See BODY, Seats and seat belts.
10. Fit front door. See BODY, Doors.
11. Fit front wing. See BODY, Exterior fittings.
12. Fit front wheel arch liner. See BODY, Exterior fittings.
13. Fit road wheel(s) and tighten nuts to correct torque. See INFORMATION, Torque wrench settings.
14. Connect all ECUs.
15. Connect alternator. See ELECTRICAL, Repairs.
16. Connect battery earth lead.
