L322 Range Rover Service Procedures
COOLING SYSTEM - V8
26-2-8
REPAIRS
7. Remove radiator assembly retaining bolts from
bonnet locking platform.
8. Ease radiator assembly rearward, release and
remove radiator retaining clips.
9. Carefully remove radiator.
Refit
1. Position radiator to mounting, fit and secure
retaining clips.
2. Position and secure radiator assembly to
bonnet locking platform.
3. Position gearbox cooler to radiator and tighten
securing screw.
4. Connect hoses to radiator and secure with
clips.
5. Fit viscous coupling.
6. Connect battery earth lead.
7. Fill cooling system.
ADJUSTMENTS, Coolant - drain, flush &
refill.
Thermostat
$% 26.45.01
Before disconnecting the battery, ensure all text and
cautions in the battery disconnection section are
observed.
GENERAL INFORMATION, Electrical
The thermostat heater is serviced with the
thermostat and must not be removed.
Remove
1. Position vehicle on lift.
2. Disconnect battery earth lead.
3. Drain cooling system
ADJUSTMENTS, Coolant - drain, flush &
refill.
4. Remove air intake hose.
V8, REPAIRS, Hose - air flow meter to
throttle body.
5. Disconnect multiplug from thermostat heater.
6. Release clip and disconnect radiator bottom
hose from thermostat housing.
M26 0870
