L322 Range Rover Service Procedures
HARNESSES
REPAIRS
86-8-3
5. Disconnect multiplug from glowplug ECU.
6. Release fuse holder and relay from 'E' box.
7. Release and disconnect multiplug from engine
harness to RH body harness.
8. Release multiplug from engine relay.
9. Release harness grommets from 'E' box.
10. Disconnect earth lead from RH suspension
turret.
11. Disconnect multiplug from boost control
modulator.
12. Disconnect multiplug from mass airflow meter.
13. Disconnect multiplug from CMP sensor.
14. Release mass airflow meter harness from
retaining clip and cable tie.
15. Feed mass airflow meter harness through
vacuum pump pipe.
M18 0766
M86 5897
M12 7791
M12 7790
M12 7465
