L322 Range Rover Service Procedures
HARNESSES
86-8-10 REPAIRS
28. Disconnect multiplug from charcoal canister
purge solenoid valve.
29. Remove 2 nuts securing engine harness to
induction manifold
30. Remove secondary air vacuum switching valve
from RH fuel injector harness securing stud.
31. Remove washer from fuel injector harness
securing stud.
32. Disconnect multiplug from RH KS.
33. Disconnect multiplugs from fuel injectors.
34. Reposition injector harness.
35. Disconnect multiplug from inhibitor switch
harness.
36. Release clips securing LH oxygen sensor lead
from gearbox bell housing.
37. Disconnect multiplug from engine wiring
harness.
38. Disconnect multiplug from CKP sensor.
M86 5701
M86 5698
M44 1860
M86 5750
