REAR SUSPENSION

REPAIRS

64-27

Valve - safety - air pressure

$% 64.50.14

Remove

1. Open both tailgates, release and fold back

parcel shelf.

2. Release spare wheel cover from clips and

remove from vehicle.

3. Depress 2 clips and disconnect air pipes from

safety valve. Remove safety valve.

Refit

1. Connect safety valve to air pipes.
2. Fit spare wheel cover and secure in clips.
3. Close parcel shelf cover.
