V8i

3

REPAIR

DRIVE BELT TENSIONER

Service repair no - 86.10.09

Remove

1. Remove drive belt from tensioner.

See Drive

Belt Renew

2. Loosen tensioner centre bolt.
3. Remove bolt and tensioner.

Refit

4. Reverse removal procedure.
