Range Rover Classic
CLUTCH
5
REPAIR
RENEWING HYDRAULIC DAMPER - Tdi
Service repair no - 33.15.05
NOTE: All flexible and pipe connections
and joints should be tightened to
15 Nm.
Remove
1. Remove the pipe between the slave cylinder and
damper.
2. Disconnect the hydraulic hose from the damper.
3. Remove the two bolts securing the damper to
the bracket and remove the damper.
Refit
4. Fit the damper to the bracket and tighten the two
bolts.
5. Connect the flexible hose to the damper.
6. Fit the pipe to the slave cylinder and to the
damper and tighten the unions.
7. Bleed the hydraulic system.
