Rover 400 Workshop Manual (1995-2000)19 · Manual gearbox - PG1
19 · Transmission

All models.

Make
Rover
Model
400 Workshop Manual
Year
1995–2000
Section
Repairs › All models.
Manual gearbox - PG1All models. · page 1 of 2

All models.

  1. Connect reverse lamp switch leads to engine harness.
  2. Position earth leads to gearbox, fit bolts and tighten.
  3. Clean push rod and clutch lever mating faces.
  4. Position clutch cylinder to bracket.
  5. Compress push rod and connect to clutch lever.
  6. Fit ’C’ clip to secure cylinder to bracket.
  7. Fit battery tray, and secure with bolts and nut.
  8. Connect dim dip resistor multiplug to engine harness.
  9. Fit air hose to turbocharger and tighten clip.
  10. Connect multiplug to MAF sensor.
  11. Fit starter motor. See ELECTRICAL, Repairs.
  12. Remove stand(s) and lower vehicle.
  13. Fill gearbox with oil. See MAINTENANCEMaintenance.

SELECTOR SHAFT OIL SEAL - ’L’ SERIES

Service repair no - 37.23.10

Remove

  1. Raise front of vehicle.

WARNING: Support on safety stands.

Selector shaft oil seal - ’l’ series – Raise front of vehicle.
  1. Remove bolt and disconnect gear change steady bar from gearbox; collect 2 washers.
  2. Remove clip retaining selector rod roll pin.
  3. Using a suitable punch, drive out roll pin securing selector rod to selector shaft. Discard roll pin.
  4. Release selector rod from selector shaft.
