Rover Rover 600 Repair Manual - Volumes 1 and 2 - 2nd Edition13 · Suspension
13 · Steering & suspension

Removal/Inspection

Make
Rover
Model
600 Rover 600 Repair Manual - Volumes 1 and 2 - 2nd Edition
Section
Repairs › Removal/Inspection
SuspensionRemoval/Inspection · page 1 of 3

Removal/Inspection

ASelf-locking nutJLower arm
BSelf-locking nutKRadius rod
CUpper arm assemblyLRadius rod rubber bushing B
DBall joint bootMSelf-locking bolts
EDamper pinch bolt (self-locking bolt)NSelf-locking nut
FDamper forkORadius rod washer
GDamper fork nut (self-locking nut)PRadius rod rubber bushing A
HRubber bushingQSelf-locking bolt
IStabiliser end rubber bushing

CAUTION: Fit new self-locking nuts after removal.

  • Check rubber bushings for damage or deterioration.
  • Be careful not to damage the ball joint boot.
  • Check damper fork, lower arm and upper arm for damage.

Note: Do not disassemble the upper arm.
