SuspensionComponents · page 1 of 3

Components

AKnuckle protectorJWheel bearing
B6 mm boltKKnuckle
CScrewLCastle nut
DSplash guardMCotter pin
ESpindle nutNBall joint boot
FWheel nutOLower ball joint
GFlange boltPSelf-locking bolt
HBrake discQCastle nut
IFront hub

CAUTION:

  • Fit new self-locking nuts after removal.
  • Fit new spindle nut after removal.
  • Inspect ball joint boot for damage and deterioration.
  • Inspect lower ball joint for freeplay or looseness.

Note: Use only weights suitable for aluminium wheels.

  • Non-genuine wheel weights may corrode and damage the aluminium wheels.
  • Before installing the brake disc, clean the mating surfaces of the front hub and inside of the brake disc.
  • Before installing the wheel, clean the mating surfaces of the brake disc and inside of the wheel.
