C063 LPG injection unit mass
- Make
- Fiat
- Model
- Ducato Factory Service Manual
- Year
- 2002–2006
- Section
- Earths › C063 LPG injection unit mass
Connectors and pin-outsC063 LPG injection unit mass
C063 LPG INJECTION UNIT MASS
| Wiring | Colour |
|---|---|
| See 12 FRONT |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 1,5 | N | X | See K185 LPG MOTOR DRIVEN PUMPCURRENT SENSOR | 6 |
| See M018A LGP UNIT (FRONT) | 61 | ||||
| See M018A LGP UNIT (FRONT) | 62 | ||||
| See M018A LGP UNIT (FRONT) | 76 | ||||
| See M018A LGP UNIT (FRONT) | 55 | ||||
