CENTRAL LOCKING - Wiring diagram
- Make
- Fiat
- Model
- Stilo Factory Service Manual
- Year
- 2001–2007
- Section
- Electrically activated devices › CENTRAL LOCKING - Wiring diagram
Wiring diagrams and electrical functionsCENTRAL LOCKING - Wiring diagram
CENTRAL LOCKING - Wiring diagram
Wiring diagram
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B2 | Junction unit under dashboard | 5505A |
| B99 | Maxifuse box on battery | 5530B |
| C15 | Facia earth, driver's side | |
| C20 | Passenger side dashboard earth | |
| C30 | Left rear earth | |
| C31 | Rear right earth | |
| D30 | Rear coupling for /front door. driver's side | |
| D31 | /Front passenger door. rear coupling | |
| D31 | Front passenger door/ rear coupling. | |
| D35 | Left /rear door. coupling | |
| D35 | Rear / rear door coupling left | |
| D36 | Rear/right door coupling right | |
| D36 | Right /rear door. rear coupling | |
| D73 | Trailer wiring connection | |
| D97 | Short circuiting coupling | |
| E40 | Alarm LED | 5560B |
| E40 | Alarm LED | 7005E |
| H1 | Ignition switch | 5520A |
| H44 | Driver's side front door electric window controls | 7005M |
| H44 | Electric window controls in driver's front door | 7005M |
| I50 | Inertia switch | 1040A |
| I50 | Inertial switch | 1040A |
| M1 | Body computer | 5505A |
| M63 | Luggage compartment control unit | 5505A |
| M64 | Passive entry control unt | |
| M66 | Driver's door control unit | 5505A |
| M67 | Passenger door control unit | 5505A |
| N50 | .Front driver's door lock geared motor | 7005N |
| N50 | Front driver's door lock geared motor. | 7005N |
| N51 | Front passenger door lock geared motor | 7005N |
| N51 | Passenger side front door lock geared motor | 7005N |
| N55 | Left rear. door lock geared motor | 7010N |
| N56 | Rear door lock geared motor right | 7010N |
| N56 | Right rear. door lock geared motor | 7010N |
| N58 | Fuel flap lock gearmotor | |
| P15 | RF aerial for passive entry control unit | |
| P93 | Aerial for alarm and central locking receiver |
Wiring diagram
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B2 | Junction unit under dashboard | 5505A |
| B99 | Maxifuse box on battery | 5530B |
| C15 | Facia earth, driver's side | |
| C20 | Passenger side dashboard earth | |
| C30 | Left rear earth | |
| C31 | Rear right earth | |
| D30 | Rear coupling for /front door. driver's side | |
| D31 | /Front passenger door. rear coupling | |
| D31 | Front passenger door/ rear coupling. | |
| D35 | Left /rear door. coupling | |
| D35 | Rear / rear door coupling left | |
| D36 | Rear/right door coupling right | |
| D36 | Right /rear door. rear coupling | |
| D73 | Trailer wiring connection | |
| D97 | Short circuiting coupling | |
| E40 | Alarm LED | 5560B |
| E40 | Alarm LED | 7005E |
| H1 | Ignition switch | 5520A |
| H44 | Driver's side front door electric window controls | 7005M |
| H44 | Electric window controls in driver's front door | 7005M |
| I50 | Inertia switch | 1040A |
| I50 | Inertial switch | 1040A |
| M1 | Body computer | 5505A |
| M63 | Luggage compartment control unit | 5505A |
| M64 | Passive entry control unt | |
| M66 | Driver's door control unit | 5505A |
| M67 | Passenger door control unit | 5505A |
| N50 | .Front driver's door lock geared motor | 7005N |
| N50 | Front driver's door lock geared motor. | 7005N |
| N51 | Front passenger door lock geared motor | 7005N |
| N51 | Passenger side front door lock geared motor | 7005N |
| N55 | Left rear. door lock geared motor | 7010N |
| N56 | Rear door lock geared motor right | 7010N |
| N56 | Right rear. door lock geared motor | 7010N |
| N58 | Fuel flap lock gearmotor | |
| P15 | RF aerial for passive entry control unit | |
| P93 | Aerial for alarm and central locking receiver |
