Discovery II
INTERIOR TRIM COMPONENTS
76-3-6
REPAIRS
7. Models with veneer trim: Release veneered
console cover and remove cigar lighter
element. Disconnect multiplugs from switch
pack and remove veneered console cover.
8. Remove 2 bolts securing forward edge of
console to transmission tunnel.
9. Release handbrake gaiter from console.
10. Remove clip and clevis pin securing cable to
handbrake lever.
11. Move handbrake to fully upward position.
12. Release electric seat switches from console.
13. Disconnect multiplugs from switches and
remove.
14. Remove 2 bolts securing rear of console to
transmission tunnel.
15. Release centre console from fascia.
16. Disconnect multiplug and bulb from cigar
lighter.
