Discovery II
SEATS
REPAIRS 76-5-33
Heating element - squab - front seat
$% 78.90.36
Remove
1. Remove front seat squab cover.
SEATS, REPAIRS, Cover - squab -
2. Disconnect heating element multiplug.
3. Carefully release heating element from squab
pad, ensuring adhesive does not tear squab
pad.
Refit
1. Ensure squab pad is free of adhesive.
2. Remove adhesive cover from new heating
element, position element and secure to squab
pad.
3. Fit front seat squab cover.
SEATS, REPAIRS, Cover - squab -
Head restraint - third row seat
$% 78.50.10
Remove
1. Fold down both third row head restaints.
2. Release upper tail gate finisher from 6 clips and
remove finisher.
3. Remove 3 bolts securing head restraint and
remove head restraint.
Refit
1. Position head restraint, fit and tighten bolts.
2. Position upper tail gate finisher and secure in
clips.
M78 0493
M78 0494
