Discovery II
TORQUE WRENCH SETTINGS
06-3
+ Apply sealant, Part No. STC 50552 to threads
Rocker shaft bolts
32 Nm
(24 lbf. ft)
Timing chain adjustable guide bolt
25 Nm
(18 lbf.ft)
Timing chain cover bolts
27 Nm
(20 lbf.ft)
Timing chain cover to cylinder block stud
7 Nm
(5.2 lbf.ft)
Timing chain fixed guide Allen screw +
25 Nm
(18 lbf.ft)
Timing chain cover to cylinder head nut and bolt
25 Nm
(18 lbf.ft)
Timing chain fixed guide (M6) bolt
10 Nm
(7 lbf.ft)
Timing chain fixed guide (M10) bolt
45 Nm
(33 lbf.ft)
Timing chain lubrication jet bolt
10 Nm
(7 lbf.ft)
Timing chain tensioner
45 Nm
(33 lbf.ft)
Torque converter to drive plate (automatic transmission) bolts
50 Nm
(37 lbf.ft)
Turbocharger heatshield bolts
10 Nm
(7 lbf.ft)
Turbocharger oil feed pipe banjo bolt
25 Nm
(18 lbf.ft)
Turbocharger to exhaust manifold nuts
30 Nm
(22 lbf.ft)
Vacuum pump oil feed pipe to cylinder head union
10 Nm
(7 lbf.ft)
Viscous fan nut
45 Nm
(33 lbf.ft)
Fuel spill return pipe unions - if fitted
20 Nm
(15 lbf.ft)
TORQUE DESCRIPTION
METRIC
IMPERIAL
