L322 Range Rover Service Procedures
CHARGING AND STARTING
86-1-10 REPAIRS
Refit
1. Clean battery tray.
2. Fit battery, align battery clamps fit and tighten
bolts to 10 Nm (7 lbf.ft).
3. Connect body earth lead to stud, fit nut and
tighten to 25 Nm (18 lbf.ft).
4. Connect gas struts to body.
5. V8 models only: Connect bonnet earth lead
and tighten nut to 6 Nm (4.4 lbf.ft).
6. Position washer harness and tube to bonnet,
secure clip.
7. Apply petroleum jelly to both terminals, fit and
tighten terminal bolts, negative lead last.
CAUTION: After re-connecting the battery,
the steering wheel must be turned to full LH
and RH lock (with engine running). This
allows the DSC system to relearn the
steering wheel position. Failure to do so will
result in a variety of instrument warning
lights being illuminated.
Carrier - battery
$% 86.15.11
Before disconnecting the battery, ensure all text and
cautions in the battery disconnection section are
observed.
GENERAL INFORMATION, Electrical
Remove
1. Remove battery.
2. Remove 9 screws securing rear of wheelarch
liner to inner wing and sill, release liner from
wing for access.
3. Remove nut securing fuel burning heater (FBH)
to underside of battery tray.
