L322 Range Rover Service Procedures
COOLING SYSTEM - V8
REPAIRS
26-2-5
9. Remove bolt securing multiplug to bell housing.
10. Release transfer gearbox breather pipe from
clip.
11. Remove 6 bolts securing coolant manifold to
cylinder heads.
12. Secure coolant pipes and remove coolant
manifold.
13. Remove harness retaining clips.
14. Discard 'O' rings and gaskets.
Refit
1. Clean coolant manifold and cylinder head
mating faces.
2. Fit new 'O' rings to coolant manifold.
3. Fit harness retaining clips.
4. Position new gaskets and coolant manifold to
cylinder heads, fit bolts and tighten to 10 Nm (7
lbf.ft).
5. Fit transfer gearbox breather pipe to clip.
6. Fit bolt securing multiplug to bell housing and
tighten to 25 Nm (18 lbf.ft).
7. Fit harness into clips.
8. Connect heater pipes to coolant manifold.
9. Fit bolt securing engine harness to coolant
manifold and tighten to 10 Nm (7 lbf.ft).
10. Fit throttle body.
11. Fit air intake plenum.
Engine - V8, REPAIRS, Acoustic
12. Connect battery earth lead.
13. Refill cooling system.
