DOORS
76-1-14 REPAIRS
Capping - front door arm rest
$% 76.34.15
Remove
1. Release 2 clips securing door handle capping
to arm rest, ease forward and remove.
NOTE: Do not carry out further dismantling if
component is removed for access only.
2. Remove 2 clips from capping.
Refit
1. Fit new clips to capping.
2. Align capping to arm rest and secure with clips.
Plastic sheet - front door
$% 76.34.18
Remove
1. Remove door airbag.
Airbag module - side impact - front door.
2. Disconnect speaker multiplug for access.
3. Remove plastic sheet.
Refit
1. Fit plastic sheet.
2. Connect multiplug to speaker.
3. Fit door airbag.
Airbag module - side impact - front door.
M76 4326
