Range Rover P38
EMISSION CONTROL
7
REPAIR
4. Release vent solenoid from EVAP canister
bracket for access to hose clip and connector.
5. Disconnect multiplug from vent solenoid.
6. Release clip and remove vent solenoid from
hose.
Refit
7. Fit vent solenoid to hose and secure hose clip.
8. Connect multiplug to vent solenoid.
9. Position vent solenoid to bracket and engage
clip.
10. Align cruise control actuator bracket to
suspension control box and secure with screws.
11. Connect battery earth lead.
EVAP CANISTER VENT SOLENOID - from 99MY
Service repair no - 17.15.47
Remove
1. Disconnect multiplug from vent solenoid.
2. Remove clip securing hose to vent solenoid.
3. Disconnect hose from vent solenoid.
CAUTION: Plug the connections.
4. Release clip and remove vent solenoid from
bracket.
Refit
5. Fit vent solenoid to bracket.
6. Connect hose to vent solenoid.
7. Fit clip to secure hose to vent solenoid.
8. Connect multiplug to vent solenoid.
