Range Rover P38
17
EMISSION CONTROL
NEW RANGE ROVER
6
REPAIR
PURGE VALVE - from 99MY
Service repair no - 17.15.39
Remove
1. Release fixings and remove battery cover.
2. Disconnect battery earth lead.
3. Disconnect multiplug from purge control valve.
4. Release purge control valve and hoses from
clips.
5. Disconnect hoses from purge control valve and
remove valve.
CAUTION: Plug the connections.
Refit
6. Position purge control valve, connect hoses and
secure with clips.
7. Fit purge control valve and hoses to clips.
8. Connect multiplug to purge control valve.
9. Connect battery earth lead.
10. Fit battery cover and secure with fixings.
EVAP CANISTER VENT SOLENOID - up to 99MY
Service repair no - 17.15.47
Remove
1. Disconnect battery earth lead.
2. Remove 2 screws securing cruise control
actuator bracket to suspension control box.
3. Position cruise control actuator assembly aside.
