Range Rover Classic Front Brake Pads Replacement
70
BRAKES
10
REPAIR
FRONT BRAKE PADS
Service repair no - 70.40.02
Service tool:
LRT-70-500 - Piston clamp
Remove
Brake pad identification
Direction of rotation
From side of vehicle, looking through disc and caliper
at inboard pad, ’D’ shaped material on rear of inboard
pad should face direction of forward rotation of road
wheel with curved part of ’D’ always at trailing end of
caliper.
Brake pad wear sensed on RH calipers.
1. Remove front road wheels.
See WHEELS AND
TYRES, Repair, Wheels
2. Disconnect battery negative lead.
3. Disconnect pad wear sensor plug (front right
hand side only).
4. Clean exterior of calipers.
5. Remove split pins from retaining pins.
6. Remove pad retaining pins and anti-rattle
springs.
7. Remove brake pads.
8. Clean exposed parts of pistons, using new brake
fluid.
