21 · General

C020 passenger side dashboard earth

Connectors and pin-outsC020 passenger side dashboard earth

C020 PASSENGER SIDE DASHBOARD EARTH

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	N		See B002H JUNCTION UNIT UNDER DASHBOARD (DASHBOARD)	10
2	1,5	NZ	X	See D047 CLOCK SPRING COUPLING	6
				See D021 DASHBOARD/AIR CONDITIONING-HEATER COUPLING	24
				See M089 STEERING LOCK CONTROL UNIT (NBS)	A4
2	1,5	N	X	See P050 CIGAR LIGHTER / CURRENT SOCKET	3
				See H036 CONTROLS ON TUNNEL	1
				See G030 GLOVE COMPARTMENT LIGHT	1
3	2,5	N		See P020A RADIO (DASHBOARD)	8
4	2,5	N		See H005A STEERING COLUMN SWITCH UNIT (DASHBOARD)	7
5	1,5	N	X	See P050 CIGAR LIGHTER / CURRENT SOCKET	3
				See H036 CONTROLS ON TUNNEL	1
				See G030 GLOVE COMPARTMENT LIGHT	1
6	0,5	N		See H003 IGNITION DEVICE	4
7	0,5	N		See M047B TYRE INFLATION PRESSURE CONTROL UNIT (DASHBOARD)	10
8	1	N	X	See M092 STEERING ANGLE CONTROL UNIT (NAS)	6
				See M091 SLEWING CONTROL UNIT	6
9	0,5	N		See I031 CLUTCH PEDAL SWITCH	2
11	0,5	NZ		See M053 AUTOMATIC TRANSMISSION GEAR SELECTOR CONTROL UNIT	2
12	0,5	N		See P020F RADIO (DASHBOARD)	12

Wiring	Colour
See 20 DASHBOARD	_

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	N		See M001I BODY COMPUTER (DASHBOARD)	8
2	0,35	NZ		See H005B STEERING COLUMN SWITCH UNIT (DASHBOARD)	9
4	0,35	NZ		See H020 HAZARD WARNING LIGHTS SWITCH	3
5	0,5	N		See M001I BODY COMPUTER (DASHBOARD)	9

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	NZ		See K062 VOLUMETRIC SENSORS FOR ALARM	2
2	0,35	NZ		See P065 ELECTRO-CHROMIC INTERIOR REAR VIEW MIRROR	2
3	0,35	NZ		See H073 SUN ROOF BLIND CONTROLS	4
4	0,5	N		See G032 PASSENGER SUN VISOR LIGHT	1
4	0,5	N		See G031 DRIVER'S SUN VISOR LIGHT	1
5	0,35	NZ		See P065 ELECTRO-CHROMIC INTERIOR REAR VIEW MIRROR	3
6	1,5	N		See P052 REAR CURRENT SOCKET	3
