Tachograph location components
- Make
- Fiat
- Model
- Ducato Factory Service Manual
- Year
- 2002–2006
- Section
- Instrument panel › Tachograph location components
Wiring diagrams and electrical functionsTachograph location components
TACHOGRAPH LOCATION COMPONENTS
Location Components
| Component code | Description | Reference to the assembly |
|---|---|---|
| B002 | JUNCTION UNIT UNDER DASHBOARD | |
| B099 | MAXI FUSE BOX ON BATTERY | |
| B101 | OPTIONAL JUNCTION UNIT UNDER THE DASHBOARD | |
| D097 | SHORT CIRCUITING COUPLING | |
| D160 | DASHBOARD/OPTIONAL DASHBOARD COUPLING | |
| D176 | OPTIONAL DASHBOARD/TACHOGRAPH COUPLING | |
| D177 | DASHBOARD/TACHOGRAPH COUPLING | |
| E005 | TACHOGRAPH | |
| E050 | INSTRUMENT PANEL | |
| H090 | SWITCH CONTROL PANEL | |
| K152 | TACHOGRAPH SENSOR |
