Central locking location components
- Make
- Fiat
- Model
- Ulysse Factory Service Manual
- Year
- 2002–2010
- Section
- Electrically activated devices › Central locking location components
Wiring diagrams and electrical functionsCentral locking location components
CENTRAL LOCKING LOCATION COMPONENTS
Location Components
Components
| Component code | Description | Reference to the assembly |
|---|---|---|
| B005 | MAXI FUSE box | |
| B098 | Additional fuse box | |
| C015 | Driver''s dashboard earth | |
| C020 | Passenger dashboard earth | |
| C030 | Left rear earth | |
| C031 | Right rear earth | |
| D020 | Dashboard/rear coupling | |
| D030 | Left front door coupling | |
| D031 | Right front door coupling | |
| D042 | Courtesy light coupling | |
| D085 | Rear/tailgate coupling | |
| D196 | Left sliding door coupling | 5505A |
| D197 | Right sliding door coupling | 5505A |
| I011 | Boot release switch | 7015B |
| I018 | Switch on left rear door | |
| I019 | Switch on right rear door | |
| I110 | Door closing switch | |
| J136 | Child lock relay | |
| M001 | Body computer | 5505A |
| M093 | Steering wheel node control unit (NVO) | 5550A |
| M171 | Sliding side door node | 5505A |
| N050 | Left front door lock geared motor | 7005N |
| N051 | Right front door lock geared motor | 7005N |
| N055 | Left rear door lock geared motor | 7020N |
| N056 | Right rear door lock geared motor | 7020N |
| N057 | Boot lock geared motor | |
| N151 | Left rear door child lock motor | |
| N152 | Right rear door child lock motor | |
| N166 | Left sliding side door lock geared motor | 7020N |
| N167 | Right sliding side door lock geared motor | 7020N |
Location Components
Components
| Component code | Description | Reference to the assembly |
|---|---|---|
| B005 | MAXI FUSE box | |
| B098 | Additional fuse box | |
| C015 | Driver''s dashboard earth | |
| C020 | Passenger dashboard earth | |
| C030 | Left rear earth | |
| C031 | Right rear earth | |
| D020 | Dashboard/rear coupling | |
| D030 | Left front door coupling | |
| D031 | Right front door coupling | |
| D042 | Courtesy light coupling | |
| D085 | Rear/tailgate coupling | |
| D196 | Left sliding door coupling | 5505A |
| D197 | Right sliding door coupling | 5505A |
| I011 | Boot release switch | 7015B |
| I018 | Switch on left rear door | |
| I019 | Switch on right rear door | |
| I110 | Door closing switch | |
| J136 | Child lock relay | |
| M001 | Body computer | 5505A |
| M093 | Steering wheel node control unit (NVO) | 5550A |
| M171 | Sliding side door node | 5505A |
| N050 | Left front door lock geared motor | 7005N |
| N051 | Right front door lock geared motor | 7005N |
| N055 | Left rear door lock geared motor | 7020N |
| N056 | Right rear door lock geared motor | 7020N |
| N057 | Boot lock geared motor | |
| N151 | Left rear door child lock motor | |
| N152 | Right rear door child lock motor | |
| N166 | Left sliding side door lock geared motor | 7020N |
| N167 | Right sliding side door lock geared motor | 7020N |
