Wiring diagrams and electrical functionsHeadlamp washer location components
HEADLAMP WASHER LOCATION COMPONENTS
Location Components
Components
| Component code | Description | Reference to the assembly |
|---|---|---|
| B001 | Engine compartment junction unit | 5,505A |
| C011 | Right front earth | |
| C015 | Driver''s dashboard earth | |
| C020 | Passenger dashboard earth | |
| D020 | Dashboard/rear coupling | |
| M001 | Body computer | 5505A |
| M093 | Steering wheel node control unit (NVO) | 5550A |
| N025 | Headlamp washer pump motor | 5050D |
