HORNS LOCATION COMPONENTS

Location Components

HORNS LOCATION COMPONENTS

Components

Component codeDescriptionReference to the assembly
B001Engine compartment junction unit5505A
C011Right front earth
C015Driver''s dashboard earth
C020Passenger dashboard earth
D020Dashboard/rear coupling
M001Body computer5505A
M093Steering wheel node control unit (NVO)5550A
P005Single tone horn5550B
