Sun roof location components
- Make
- Fiat
- Model
- Ulysse Factory Service Manual
- Year
- 2002–2010
- Section
- Electrically activated devices › Sun roof location components
Wiring diagrams and electrical functionsSun roof location components
SUN ROOF LOCATION COMPONENTS
Location Components
Components
| Component code | Description | Reference to the assembly |
|---|---|---|
| B005 | MAXI FUSE box | |
| B098 | Additional fuse box | |
| C020 | Passenger dashboard earth | |
| C031 | Right rear earth | |
| D030 | Left front door coupling | |
| D042 | Courtesy light coupling | |
| H051 | Electric window and rear view mirror controls on driver''s front door | 7005M |
| H061 | Front sun roof switch | 7030B |
| I120 | Centre sun roof switch | |
| I121 | Rear sun roof switch | |
| I122 | Centre and rear sun roof switch | 7030B |
| M001 | Body computer | 5505A |
| M066 | Driver''s door control unit (NPG) | 5505A |
| N036 | Front sun roof motor | 5005A |
| N155 | Centre sun roof motor | 7030B |
| N156 | Rear sun roof motor | 7030B |
