Discovery II
AUTOMATIC GEARBOX - ZF4HP22 - 24
44-44
REPAIRS
Seal - rear extension housing
$% 44.20.18
Remove
1. Remove transfer box
REPAIRS, Transfer box - Diesel.
2. Drain automatic gearbox oil.
3. Remove rear extension housing oil seal from
gearbox.
Refit
1. Clean oil seal recess in gearbox and running
surface on input shaft.
2. Lubricate oil seal running surface with
transmission oil.
3. Using tool LRT-44-001 fit oil seal to extension
housing.
4. Fit transfer box
REPAIRS, Transfer box - Diesel.
5. Fill automatic gearbox with oil.
