Discovery II
HEATING AND VENTILATION
80-28
REPAIRS
Resistor pack - power resistor A/C
$% 80.20.17
Remove
1. Remove 4 studs securing toe board and
remove toe board.
2. Remove 4 screws securing glove box, release
catch and remove glove box.
3. Disconnect multiplug from resistor.
4. Remove screws securing resistor, release and
remove resistor.
Refit
1. Position resistor and secure with screw.
2. Connect multiplug to resistor.
3. Position glove box, fit and tighten screws.
4. Position toe board and secure with studs.
