Discovery II
HEATING AND VENTILATION
80-18
REPAIRS
Refit
1. Position servo and connect operating lever.
2. Fit and tighten screws securing servo.
3. Connect multiplug to servo.
4. Position ECU assembly, fit and tighten nuts.
5. Position BCM, fit and tighten bolt.
6. Position toe board and secure with studs.
7. Position glove box, fit and tighten screws.
Switch - recirculation control
$% 80.10.21
Remove
1. Remove louvre panel assembly.
REPAIRS, Louvre panel assembly - centre
fascia.
2. Disconnect multiplug from recirculation switch.
3. Remove recirculation switch from heater
control panel.
Refit
1. Fit recirculation switch to heater control panel
and connect multiplug.
2. Fit louvre panel assembly.
