L322 Range Rover Service Procedures
LIGHTING
REPAIRS 86-2-11
8. Remove switch assembly from finisher.
Refit
1. Fit switch assembly to finisher.
2. Connect multiplugs.
3. Fit finisher to fascia and secure with screws.
4. Fit face level air vents.
REPAIRS, Fresh air vent - face level.
5. Fit fascia end closing panels.
6. Fit 'A' post finisher.
Trim finisher - 'A' post - upper.
Switch - hazard warning
$% 86.65.50
Remove
1. Release 4 internal clips securing air vent to
finisher, apply an even outward pressure until
the last clip is released.
2. Disconnect multiplug and remove hazard
warning switch.
Refit
1. Position hazard warning switch and connect
multiplug.
2. Fit and secure air vent.
