L322 Range Rover Service Procedures
STEERING
REPAIRS
57-33
Switch - column adjustment - control
$% 57.41.05
Remove
1. Remove rotary coupler.
2. Release clip securing switch to rotary coupler
and remove switch assembly.
Refit
1. Position switch assembly to rotary coupler, fit
and secure clip.
2. Fit rotary coupler.
Ball joint - track rod
$% 57.55.07
Remove
1. Raise front of vehicle.
WARNING: Do not work on or under a
vehicle supported only by a jack. Always
support the vehicle on safety stands.
2. Remove front road wheel.
3. Loosen track rod end locknut.
4. Remove nut from ball pin and discard.
5. Fit an M14 nut to ball pin, flush with end of pin.
6. Using LRT-57-036 separate ball pin from
steering arm. Remove M14 nut and release ball
pin from steering arm.
7. Remove track rod end, note the number of
turns for refit.
8. Remove and discard locking ring.
Refit
1. Fit locking ring ensuring taper faces towards
track rod end.
M57 1112
LRT-57-036
