Cruise ControlDiagnostic Aids · page 31 of 131
*
In some cases Delphi will actually be printed on the connector. If Delphi is not printed on the connector, look for PED. In both cases there is no
specific orientation for Delphi or PED and they can appear anywhere on the connector.
*
FCI connectors may have the FCI logo on their connectors. The logo is the letters FCI with an "A" above it.
