G8 V8-6.0L (2009)
1. While depressing the lock, pull the two connector halves apart.
Note: The TPA is fragile and may break if not done carefully.
2. Use a small flat-blade tool to very carefully push the terminal position assurance (TPA) towards the face of the connector on both sides of the
connector.
3. View of the male half of the connector with female terminals.
